BASIC INFO
|
Model
|
CAPD247
|
CAPD347 | |
| Printing | Method |
Thermal line dot printing
|
|
| Number of dots/line |
432
|
576
|
|
| Resolution(dots/mm) |
8
|
||
| Paper width(mm) |
58
|
80
|
|
| Printing width(mm) |
54
|
72
|
|
| Speed (mm/sec)max |
200
|
||
| Paper path |
Curved
|
||
|
Detection |
Head temperature |
By thermistor
|
|
| Platen position |
By mechanical switch
|
||
| Out of paper |
By photo interrupter
|
||
| Cutter home position |
By photo interrupter
|
||
| Power supply (V) | Operation voltage (Vdd) |
2.7 to 3.6/ 4.75 to 5.25
|
|
| Operation voltage (Vp) |
21.6 to 26.4
|
||
|
Peak current (A) |
Head |
2.61 (26.4V/144 dots)
|
|
|
5.23 (26.4V/288 dots)
|
|||
| Motor |
0.44
|
0.52 | |
| Cutter |
0.64
|
||
|
Auto Cutting |
Method |
Slide type
|
|
| Paper thickness (µm) |
54 to 91 *1
|
||
| Cutting type |
Partial cut / Full cut (Leave center point)
|
||
| Operation time (sec/cycle) max |
Approx. 0.5
|
||
| Cutting pitch(mm)min |
10
|
||
| Cut frequency(cut/min) max |
30
|
||
| Service life | Pulse activation(pulse) |
100 million
|
|
| Abrasion resistance(km) |
100 *1
|
||
| Paper cutting(cut) |
1,000,000 *1
|
||
| Operating temperature(°C) |
-10 to 50
|
||
| Dimensions(WxHxD mm) |
83.1 x 35.4 x 26.9 *2
|
105.1 x 35.4 x 27.2 *2
|
|
| Mass(g) |
Approx. 131
|
Approx. 154
|
|
|
|
*1 Use recommended thermal papers *2 Excluding mounting part |
Interface / CPU *3
|
||||||||||||
