BASIC INFO
MLT-289XS -MDX-630P_
MLT-289
MLT-289
Removable platen
Removable platen
Without platen model
available
MLT-288
Paper roll
58mm
52.5mm/sec
Printing Speed
Removable
Platen
Features
- 58 mm paper width
- 5V operation
- 52.5 mm/sec printing speed (Operating at 7.2V)
- Small size and light-weight
- Platen removable design
Papge Top
Specifications
| Printing method | Thermal dot line printing method | |
|---|---|---|
| Total dots | 384 dots/line | |
| Dot density | 8 dots/mm | |
| Printing width | 48mm | |
| Printing speed | Max. 52.5mm/sec. (420 dot-lines/sec) | |
| Paper width | 58mm | |
| Paper feeding pitch | 0.125mm | |
| Sensors | PE sensor | Photo-interrupter |
| Head temperature | Thermistor | |
| Head-up | Mechanical switch | |
| Operating voltage *1 | VH | DC 4.2 to 8.5V |
| Vdd | DC 4.75 to 5.25V | |
| Current consumption | Head (VH=5V) | Max.: 2.5A approx. |
| Motor (VH=7.2V) | Max.: 0.5A approx. | |
| Recommended paper | Width | 58 mm |
| Thickness | 65mµ | |
| Paper diameter *2 | φ60mm or less | |
| Paper (Manufacturer) | TF50KS-E2C (Nippon Paper) | |
| Reliability *3 | Head pulse-resistance | 100 million pulses or more |
| Haed wear-resistance | 50km or more | |
| Environment | Operation |
Temperature: 0 to 45°C Humidity: 35 to 85% RH (No condensation) |
| Storage |
Temperature: -20 to 60°C Humidity: 10 to 90% RH (No condensation) |
|
| External dimensions | 76.8 (W) × 37 (D) × 16 (H) mm | |
| Weight | Approx. 50g | |
-
(*1): Voltage drop at maximum current may cause the print quality problem. Please check it carefully in your environment such as control board, wiring, etc. Also please keep the voltage within the speci? ed voltage range even by the voltage drop.
-
(*2): The number of diameter varies depending on the conditions.
-
(*3): Normal temperature at 25°C, normal humidity, 12.5% printing ratio, rated energy and by use of the recommended print paper.
Papge Top
Type Classification
|
MLT-289
(1) |
|||
|---|---|---|---|
| (1) Model | MLT-289 | ||
