- Reliable printer mechanism
- Portable type
- Easy paper loading
- Wireless blutooth connection
- Diagram/logo printing
- Long standby time
- Customized case color
- Supporting Android/windows/Mac OS
|
Type |
Portable thermal printer |
|
Printing method
|
Thermal dot line printing |
|
Paper width |
58mm |
| Paper roll diameter |
Max 40 mm |
|
Outside dimension |
110mm*78mm*42mm |
|
Weight |
Approx 300 g(including battery and paper roll) |
|
Dot/line |
16 Chinese /line or 32 English /line |
|
Chinese coding scheme |
GBK |
|
Font stock
|
ASCII GB18030
|
|
Barcode /bitmap |
1D:UPC-A;UPC-E;EAN-13;EAN-8;CODE39;ITF25;CODEBAR;CODE93;CODE128 ; 2D: QR CODE;Bitmap |
| speed | 90mm/s(in full power) |
| Reliability | 1,000,000 characters |
| Printing type | languages,numbers,LOGO,diagram |
| Resolution | 8 dots/mm |
| Interface | RS-232/USB(by optional)+ Bluetooth |
| Power supply | Rechargeable lithium battery 1000mAh(charging time 2 hours) |
| Adaptor | Input :AC90~230V,output: DC9V1A |
| Standby current | Below 20uA |
| Standby time | Automatic power off ( after 15 minutes standby) |
| Abnormal detection | Out-paper,low power,overheating |
| Paper loading method | Easy loading from front panel |
| Cutting paper method | Tearing paper out |
| Command set | ESC/POS |
·application
Logistics,transportation,postal,city inspectors,tax,meters,retails,dressing and more
