BASIC INFO
ticket dispenser lottery device id automation thermal kiosk printer
Product Description
Features:
Brand name printer mechanism Reliable auto cutter Compact panel mounted structure Ultra high speed
Wide input voltage range Full/partial cutting (by adjustable)
Rear paper auto loading
Competitive Advantage:
OEM offer
Brand-name printer parts
Android system support
Customization offer
Prompt delivery
Small order accepted
Sample is available
ROHS &CE certificatedApplications:
Information kiosk; gas pump station; public payment terminal; ID automation; lottery device; ticket vendor; parking system; queue management machine and more.
YJX-D245
ticket dispenser lottery device id automation thermal kiosk printer
|
Type
|
58mm thermal kiosk printer
|
|
|
mechanism：
|
CAPD245
|
|
|
Printing method
|
Thermal dot line printing
|
|
|
Dots/line
|
384 dots/line
|
|
|
Dot pitch
|
8 dot/mm
|
|
|
Paper width
|
58 mm
|
|
|
Printing width
|
48 mm
|
|
|
Paper thickness
|
54~91 um
|
|
|
Printing speed
|
150 mm/s
|
|
|
Paper loading
|
Paper auto loading
|
|
|
Sensors
|
Head temperature
|
Thermistor
|
|
Paper press shaft
|
Mechanical switch
|
|
|
Paper end
|
Photo interrupter
|
|
|
Font size
|
ASCII:9*17;12*24; Chinese: 24*24
|
|
|
Power supply
|
Logic circuit
|
2.6~3.6 V
|
|
Motor
|
4.75 ~9.5 V
|
|
|
Reliability
|
Circuit: over 1,000,000,000 pulses
Cutter: over 7,000,000 cuts Thermal head: over 100 km MCBF: 37,000,000 lines |
|
|
Ambient environment
|
Work temperature
|
-10 ℃~50℃
|
|
Work humidity
|
20~85% RH
|
|
|
Storage temperature
|
-25℃~70℃
|
|
|
Storage temperature
|
10~90% RH
|
|
|
Dimension (L*W*H)
|
117.85*103.5*93 mm
|
|
|
Weight
|
Approx 0.45 kg
|
|
|
Interface
|
RS-232 /USB
|
|
|
power supply
|
DC 9~24V/2.5A
|
|
|
Command set
|
ESC/POS
|
|
|
Barcode
|
supported
|
|
|
Firmware location
|
2 M NV Flash memory
|
|
|
Buffer
|
4 KB
|
|
|
SRAM
|
20 KB
|
|
|
Driver
|
USB driver
|
|
|
System
|
Windows/Linux/Android OS
|
|
