Printers for Shimadzu Balances EP-110 EP-100 Printers

Product Item：Printers for Shimadzu Balances EP-110 EP-100 Print
Category： Other print heads
Printers for Shimadzu Balances EP-110 EP-100 Printers
Product Manual：Printers for Shimadzu Balances EP-110 EP-100 Printers EP-110/EP-100 Printers for Shimadzu Balances

BASIC INFO

EP-110/EP-100 Printers

EP-110/EP-100
Printers for Shimadzu Balances

Features

Built-In Clock

Enables printing time and date information even with a balance that doesn't have a clock function.

Enhanced Support for ISO/GLP

EP-100 can output time/signature information. In addition to this information, EP-110 can output other information based on your demands together with measured values. See samples below for details.

OLED Dot Matrix Display (EP-110 only)

Offers easy-to-read, brightly illuminated OLED display.

Automatically Set

Automatically sets the appropriate communication with a balance. An operator doesn't have to worry about its setting.

EP-110 Provides further applications

Pipette calibration Calibrate capacity of pipette and flask
User-defined calculation Operator can set coefficients (handy for converting result to local unit)
Tare/Net/Gross weight printing Print out Tare/Net/Gross weight separately
SUM mode Print out the total values of samples
Averaging mode Print out the average of samples
Formulation mode Print out each sample's weight independently when blending samples
Comparator mode Print out result whether weight of sample is within target range
Interval printing mode Print out current weight at a regular interval

Printout Samples

Normal Mode

*Operator can choose items to print out.

Statistical Calculation Mode

Specifications

Compatible Balance Models:
AU, AT, UW/UX, TW/TX, TXB, BW-K/BX-K, ELB, AW/AX/AY series, MOC63u

Model	EP-100	EP-110
Display	-	OLED 128 x 64 Dot Matrix Display
Protected Date Setting	-	Prevents unintended changes of time and date setting.
Printing	Method : 8-pin reciprocating impact dot matrix Speed : Approx. 1.7 lines/sec. Printer head life : 1 million lines Character size : Approx. W1.7 mm × H2.6 mm
Interface	RS-232 DB9
Power Supply	AC adapter : Input 100 to 240 V AC, 50/60 Hz; Output 12 V DC /1500 mA Power consumption : 8 W (while printing) Standby power : 0.5 W (when not printing)
Installation Environment	Temperature 5 to 45 °C, humidity 10 to 80 % No condensation

Maintenance Parts

Item Name	Specifications
Recording Paper (10 rolls)	W57 x dia. 50 mm, Standard paper
Labeling Paper (10 rolls)	W57 x dia. 50 mm, Labeling paper
Ink Ribbon (5 pcs)	Black print (ERC-22, long-life type)
AC Adapter	12 V/1.5 A
Connection Cable	DB9 Female - DIN8-262 Male, 1.2 m in length
