BASIC INFO
FTP-62DMCL101
Mechanism, 2-inch, 58mm, 100mm/s, 60-85µm, 38mm FPC, 5V, rear paper feed, platen release, w/o platen detect switch, straight paper path, 50km head life.
- Overview
- Technical Specifications
- Documentation
| Type | Low Voltage |
|---|---|
| Status | Discontinued |
| Alternate 1 | FTP-62DMCL101#02 |
| Part Type | Mechanism |
| Safety Standards | UL File No. E171434 |
| RoHS Compliant | RoHS compliant |
Technical Specifications
Technical Specifications
| Paper Width (inch/mm) | 2-inch / 58mm |
|---|---|
| Paper Path | - |
| Speed (mm/s) | 100 |
| Cutter | No |
| Platen | Detachable |
Documentation
| Datasheet | FTP-62DMCL101 [595KB] |
|---|---|
| Application Notes | FTP-600 Series |
