BASIC INFO
1box=10pcs ,
| Model |
DPU-44-40B
|
|
| Printing | Method |
Thermal serial dot printing
|
| Number of dots/line(HxW) |
9 x 320
|
|
| Paper width(mm) |
112
|
|
| Printing width(mm) |
89.6
|
|
| Speed(character/sec) max |
52.5
|
|
| Character matrix(HxW dots) |
9 x 7
|
|
| Character size(HxW mm) |
2.5 x 1.9, 2.5 x 0.9(Condensed)
|
|
| Number of columns |
40, 80(Condensed)
|
|
| Character type |
Extend Graphics Character set, Alphanumeric, International Characters, Katakana Character set
|
|
| Power supply(V) |
Option: Specified AC adapter, Ni-MH Battery
|
|
| Battery |
Without(option)
|
|
| Communication interface |
Parallel(36pin Amphenol), Serial(9pin D-SUB)
|
|
| Input buffer |
28K bytes
|
|
| Command |
ESC/P*1 conformity
|
|
| Cutting |
Tear bar
|
|
| Operating Temperature (oC) |
0 to 40
|
|
| Service life(line) |
500,000 *1
|
|
| Dimensions(WxHxD mm) |
160.0 x 170.0 x 66.5(printer unit only) *2
|
|
| Mass(g) |
Approx.580(without Battery)
|
|
| Standard |
FCC, CE, VCCI, CCC
|
|
| Option |
AC Adapter, Battery
|
|
|
. *1 Use recommended thermal papers *2 Excluding protrusion.
|
|
Serial interface specification
|
||||||||||||
|
|
||||||||||||
|
Parallel interface specification
|
