DPU-3445-30A-E

PrinterDPU 3445Print methodDirect thermalCharacters in line52 (basic) *1Character size24 dots x 24 dotsDots in line832 dotsDots density8 dots/mmPrint width / paper width104mm/112mmPrint speed50mm/sek. (max.)Operating temperature50C – 400 CHumidity30% do 80% (non-condensation)Dimension (width x depth x high)160mm x 89 mm x 29.5 mm *2Dimensions with a paper tray (width x depth x high)
160mm x 164.2mm x 59mmWeight250 g (printer)Interface serial RS-232Modular socket 6 pinsIR connectorIrDA Ver. 1.0BP-3007-A1 battery (option)Lit-Ion 7.2 V 1500 mAhPower adapter PW-3009-W1 (option)100-240VAC 9.3VDC/3ABatterys power adapter BC-3008-W1 (option)100-240VAC 8.4VDC 17 WPaper tray RH-48-00 (option)Paper roll feeder 112mm x 20mPower cable CB-A01-E1Standard computer cable
