BASIC INFO
UTP-58S24A
Sanei µTP-58
| Model |
µTP-58 20A |
µTP-58 24A |
µTP-58 G27A |
µTP-58 S20A |
µTP-58 S24A |
µTP-58 GS27A |
|---|---|---|---|---|---|---|
| Printing method |
7 dots serial thermal （uTP-5820A/uTP-5824A/uTP-58S20A/uTP-58S24A） 8 dots serial thermal （uTP-58G27A/uTP-58GS27A） |
|||||
| Printing speed | 0.8-0.9lines/sec | |||||
| Character dot matrix | 7x5 dot matrix | 8x6 dot matrix | ||||
| Interface | Centronics | RS-232C | ||||
| Font | JIS-C6220＋Social pattern 250 kinds | |||||
| Power supply | 5V±5％,3A | |||||
| Current consumption | Idle time : 50mA or less , Printing : 3.0A max. | |||||
| Dimensions | 105.5(W)x68(H)x121(D)mm | |||||
| Weight （including paper、mounting parts） | ||||||
