BASIC INFO
Thermal Printer Mechanism
LTPA245
-
Max printing speed: 90mm/sec
-
-
Easy paper operation
- Platen latch function
- Compact and Light-weight
| Model | LTPA245 | |
|---|---|---|
| *1 Use recommended thermal papers *2 Excluding protrusion | ||
| Printing | Method | Thermal line dot printing |
| Number of dots/line | 384 | |
| Resolution(dots/mm) | 8 | |
| Paper width(mm) |
58
|
|
| Printing width(mm) | 48 | |
| Speed(mm/sec)max | 90 | |
| Paper path | Curved | |
| Detection | Head temperature | By thermistor |
| Out of paper | By photo interrupter | |
| Power supply(V) | Operation voltage(Vdd) | 2.7 to 3.6 / 4.75 to 5.25 |
| Operation voltage(Vp) | 4.5 to 8.5 | |
| Peak current(A) | Head | 2.6(8.5V / 64 dots) |
| Motor | 0.6 | |
| Service life | Pulse activation(pulse) | 100million |
| Abrasion resistance(km) | 50*1 | |
| Operating temperature (°C) | 0 to 50 | |
| Dimensions(W x D x H mm) | 69.2 x 28.3 x 31.7 *2 | |
| Mass(g) | Approx.42 | |
|
|
