MTP102-16B-E

BASIC INFO

Model		MTP102-16B	MTP201-20B	MTP201-24B	MTP401-40B	MTP201-G166
Printing	Type	Character				Graphic
	Method	Thermal serial dot printing
	Paper width(mm)	38	58		80	58
	Printing width(mm)	26.4	45.9	46	66.7	46
	Speed(line/sec) max	1.2	1.0	0.9	0.5	0.9
	Paper path	Curved
	Character matrix(HxW dots)	7 x 5
	Character size(HxW mm)	2.4 x 1.2	2.4 x 1.6	2.4 x 1.4	2.4 x 1.2	2.4 x 1.4
	Number of columns	16	20	24	40	24
	Direction	Left to right
	Timing	Synchronized with the tachogenerator
	Line spacing(mm)	3.8				2.8
	Character spacing(dot)	2				0
Detection		Mechanical Switch
Power supply(V)		4.0 to 6.0
Peak current(A)		3.2(5V on)
Service life (Lines)		500,000 ^*1
Operating temperature(°C)		0 to 50
Dimensions(WxHxD mm)		48.0 x 31.0 x 13.8 ^*2	70.0 x 34.0 x 14.4 ^*2		91.5 x 35.5 x 20.0^*2	70.0 x 34.0 x 14.4 ^*2
Mass(g)		Approx.35	Approx.40		Approx.50	Approx.40
