EPSON M-192
Epson M-192: 57.5mm, 5V, Standard Ribbon
The M-190 series offers much better performance than the M-150 series. A dramatic improvement in printing speed brings new advances to applications such as CAT/EFT and measuring instruments.
Product Description
M-190series
|
Specifications
|
M-190 Series
|
|
Model
|
M-190
|
M-190G
|
M-192
|
M-192G
|
|
Print method
|
shuttle impact dot matrix
|
|
Font
|
5 × 7
|
|
Number of columns
|
24 columns
|
24columns
|
40 columns
|
40 columns
|
|
Character size
|
1.7(W)×2.6(H)mm
|
1.7(w)×2.6(H)mm
|
1.1(W)×2.6(H)mm
|
1.1(W)×2.6(H)mm
|
|
The number of rows of space
|
3.7 mm (In case of 5 x 7 font and 3 dots / line paper feed)
|
|
|
2.0 mm
|
2.0 mm
|
1.2mm
|
1.2 mm
|
|
Points
|
144dots / line
|
144dos / line
|
240dos / line
|
240dos/ line
|
|
Print speed
|
2.5lines/ sec (4.8V DC)
|
2.7lines / sec(4.8V DC)
|
1.5lines / sec (4.8V DC)
|
1.8lines/ sec (4.8V DC)
|
|
Motor
|
Voltage
|
3.8---5.2V DC
|
|
Average current
|
0.35A (4.8V DC)
|
|
paper
|
Paper mode
|
Roll paper
|
|
Size
|
Max 57.5 ± 0.5mm(W) × 83 mm
|
|
Thickness
|
0.06----0.085mm
|
|
Copy capability
|
Original and one copy
|
|
Ribbon
|
ERC-09 / 22/44
|
|
Operating Temperature
|
-10° -- 50°C
|
|
MCBF
|
1.5 × 106 lines
|
1.5 × 106 lines
|
1.0 × 106 lines
|
1.0× 106 lines
|
|
Printer Life
|
2.25 × 106 lines
|
2.25 × 106 lines
|
1.5 × 106 lines
|
1.5 × 106 lines
|
|
Appearance Dimensions
|
91.0 (W)× 46.9 (D) × 15.8 (H) mm
|
|
Weight Approx
|
Approx 100g
|
|
