This product is RoHS compliant.
NEW AT  NEW AT  NEW AT  Seiko Instruments Thermal Printers
2732
For quantities greater than listed, call for quote.

stock no.
SII
Part No. Fig. Description Price Each
1 5
LTPD245A-384-E LTPD245A-384-E D 2" Mechanism, 5V, EZOP, horizontal 43.01 42.05
LTPD245B-384-E LTPD245B-384-E D 2" Mechanism, 5V, EZOP, vertical 43.01 42.05
LTPD245C-384-E LTPD245C-384-E D 2" Mechanism, 5V, auto-loading, horizontal 43.01 42.05
LTPD345A-576-E LTPD345A-576-E D 3" Mechanism, 5V, EZOP, horizontal 60.80 59.45
LTPD345B-576-E LTPD345B-576-E D 3" Mechanism, 5V, EZOP, vertical 60.80 59.45
CAPD245A-E CAPD245A-E E 2" Mechanism, 5V, with auto-cutter 63.03 61.63
CAPD345A-E CAPD345A-E E 3" Mechanism, 5V, with auto-cutter 91.06 89.03
Accessories
IFD501-01UK-E IFD501-01UK-E - IF Board LTPD245/345 USB 148.30 145.00
PTD50P01-E PTD50P01-E - CPU for LTPD245/345 42.27 41.33
DC-04100A-E DC-04100A-E - DC Power cable IFG/APU-G/IF9000/APU9000 7.42 7.25
OC-D0730A-E OC-D0730A-E - Serial DC9 connector cable for IFD 8.90 8.70
OC-D1430A-E OC-D1430A-E - Switch cable for IFD 3.71 3.63
For quantities greater than listed, call for quote.

stock no.
SII
Part No. Fig.
Dots
Per
Line
Paper
Width
(mm)
Characters
Per Line
Print
Speed
Weight
(g)
Dimensions: mm Price Each
W D H 1 5
MTP102-16BE MTP102-16B-E A 7 x 110 26.4 16 1.2 cl/s, 19 CPS 35 48.0 31.0 13.8 31.14 30.45
MTP201-24BE MTP201-24B-E B 7 x 166 46.0 24 0.9 cl/s, 22 CPS 40 70.0 34.0 14.4 31.14 30.45
MTP201-G166E MTP201-G166-E B 8 x 166 46.0 24 (Graphic) 0.9 cl/s, 22 CPS 40 70.0 34.0 14.4 32.63 31.90
For quantities greater than listed, call for quote.

stock no.
SII
Part No. Fig.
Dots
Per
Line
Paper
Width
(mm)
Characters
Per Line
Print
Speed
Weight
(g)
Dimensions: mm Price Each
W D H 1 5
LTP2242C-S432AE LTP2242C-S432A-E C 432 54 27 90mm/s, 18 cl/s 120 85.2 61.4 27.0 74.89 73.23
For quantities greater than listed, call for quote.

stock no.
SII
Part No. Fig. Description Price Each
1 5
LTPD247A-432-E LTPD247A-432-E D 2" Mechanism, 24V, EZOP, horizontal 48.94 47.85
LTPD247B-432-E LTPD247B-432-E D 2" Mechanism, 24V, EZOP, vertical 48.94 47.85
LTPD347A-576-E LTPD347A-576-E D 3" Mechanism, 24V, EZOP, horizontal 69.70 68.15
LTPD347B-576-E LTPD347B-576-E D 3" Mechanism, 24V, EZOP, vertical 69.70 68.15
CAPD247A-E CAPD247A-E E 2" Mechanism, 24V, with auto-cutter 69.70 68.15
CAPD347A-E CAPD347A-E E 3" Mechanism, 24V, with auto-cutter 105.29 102.95
Accessories
IFD001-01UK-E IFD001-01UK-E - IF Board LTPD247/347 USB 155.72 152.25
IFD001-01SK-E IFD001-01SK-E - IF Board LTPD247/347 Serial 155.72 152.25
PTD00P01-E PTD00P01-E - CPU for LTPD247/347 42.27 41.33
DC-04100A-E DC-04100A-E - DC Power cable IFG/APU-G/IF9000/APU9000 7.42 7.25
OC-D0730A-E OC-D0730A-E - Serial DC9 connector cable for IFD 8.90 8.70
OC-D1430A-E OC-D1430A-E - Switch cable for IFD 3.71 3.63
SEIKO INSTRUMENTS Thermal Print Mechanisms
SEIKO MTP SERIES: THERMAL PRINT MECHANISMS
SEIKO LTP-2000 SERIES: THERMAL PRINT MECHANISM
SEIKO LTPD and CAPD (5) Series: Low-Voltage Printer Mechanisms
SEIKO LTPD and CAPD (7) Series: 24V Printer Mechanisms
Applications:
• Mobile devices
• Medical equipment
Applications:
• Medical equipment
• POS devices
Features:
• 2" and 3" print width models
• High speed printing
• EZ-OP clamshell and auto-loading
paper replacement options
Applications:
• Hand-held terminals
• POS
• Kiosk
• Test equipment
• Medical
Features:
• Quiet and compact design
• High resolution printing (8 dots/mm)
• High print speeds up to 90mm/sec
• Voltage: 24V
Applications:
• Calculators
• Measuring instruments
• Medical devices
Features:
• Compact, lightweight design
• High-reliability
• Suitable for battery operation
• Designed for versatile applications
• Silent, non-impact system
• Voltage: 5VDC
• Current: 3.2A max. printing
• Platen latch for better shock absorption
• Built-in auto-cutter (CAPD models)
• Choice of horizontal and vertical orientations
Features:
• Choice of horizontal and vertical orientations
• Platen latch for better shock absorption
• EZ-OP clamshell-style paper replacement
• Available built-in auto-cutter (CAPD models)
A
B
C
D
F
New low voltage LTPD and CAPD (with auto-cutter) series direct thermal printer mechanisms tackle the challenges of designing smaller, faster,
more reliable mobile devices. These new mechanisms deliver exceptional value with dramatic advances in design flexibility, reliability and printing
performance.
MTP Series thermal printers offer a wide range of features, making them ideal for applications where size, portability, low power consumption,
battery operation and affordability are important factors. This series provides the benefit of hardcopy printouts for verifying results or retaining
records from an array of small or handheld portable instruments.
The versatile line of EZ-OP thermal mechanisms, make changing and reloading the paper stock literally a snap and the rugged and reliable
LTP-2000 series, offers long service life. All are ideal solutions for applications where quiet, high-performance, cost-effective printing
components are required.
24V LTPD and CAPD (with auto-cutter) series printer mechanisms help you solve the challenges of designing smaller, more robust, more reliable
devices. And by offering greater design flexibility and industry leading value, these embedded printers are the ideal solution for meeting aggressive
product release timelines and cost targets.
