BASIC INFO
- Resolution: 8 dots/mm
| Model | CAP06-247 | CAP06-347 | |
|---|---|---|---|
| *1 Use recommended thermal papers. *2 Excluding protrusion. | |||
| Printing | Method | Thermal line dot printing | |
| Number of dots/line | 432 | 576 | |
| Resolution(dots/mm) | 8 | ||
| Paper width(mm) |
58
|
58 / 80
|
|
| Printing width(mm) | 54 | 72 | |
| Speed(mm/sec)max | 250 | ||
| Paper path | Curved | ||
| Detection | Head temperature | By thermistor | |
| Platen position | By mechanical switch | ||
| Out of paper | By photo interrupter | ||
| Cutter home position | By photo interrupter | ||
| Power supply(V) | Operation voltage(Vdd) | 3.0 to 3.6 | |
| Operation voltage(Vp) | 21.6 to 26.4 | ||
| Peak current(A) | Head | 10.3(26.4V/288dots) | 10.2(26.4V/288dots) |
| Motor | 1.0 | ||
| Cutter | 0.64 | ||
| Auto cutter | Method | Slide type | |
| Paper thickness (µm) | 48 to 80*1 | ||
| Cutting type | Full cut / Partial cut (Leave center point) | ||
| Operating time(sec/cycle)max | 0.5 | ||
| Cutting pitch(mm)min | 10 | ||
| Cut frequency(cut/min)max | 30 | ||
| Service life | Pulse activation(pulse) | 150 million | |
| Abrasion resistance(km) | 150 | ||
| Paper cutting(cut) | 1,500,000 | ||
| Operating temperature (°C) | -10 to 50 | ||
| Dimensions(W x D x H mm) | 87.5 x 43.9 x 27.2 *2 | 106.5 x 43.9 x 27.2*2 | |
| Mass(g) | Approx.140 |
Approx.163 |
|
