2inch Mobile Dot Matrix Bluetooth Printer

  • Category: Products
  • Product Manual:2inch Mobile Dot Matrix Bluetooth Printer,M-190G,M-192G
BASIC INFO

2inch Mobile Dot Matrix Bluetooth Printer

YJX192G/190G

Overview

 Dot Matrix Bluetooth Printer
• Paper width adjustable : 58mm
• ESC/POS command compatible
• Support Various Drivers
• Support Bluetooth 2.0 and RS232
• Auto black label Detection and Location


 Specificaions

Adapter

Input AC 110V-240V Output DC 9V-1.5A

Battery

7.4v-1400mah

Printing life

1.5million lines

Weight

200g (package included 500g)

Size

120mm*100mm*50mm

Communication

Interface

Bluetooth/USB

Bluetooth

Bluetooth 4.0

Printing parameters

Printing method

8 needles unidirectional printing

Print Width

44mm (24 Chinese characters/line 48 English words/line)

Printing

Printing Speed

5.5MM/S  or  2.1MM/S

Printer Width

48mm

Paper Width

58mm

Paper thickness

0.06-0.08mm

Sensor

Black mark sensor

Installed Character

ASII (8*16 12*24 16*32 24*48 32*64)   GB13080 (13*13  24*24  68*48)

Instruction system

POS/ESC

Resolution

5 dot /mm

Paper Cut

Manually

System Language

English/Chinese

Support System

Android/ IOS/Windows/Saipan/Win CE

Paper type

2 page copy paper

Paper roll

Max 40mm

Environment

Storage Temp

-20--70

Humidity

0-95%

Packing List

1* printer  1*adapter  1* paper roll  1 box package
