BASIC INFO
PLUS2
Panel printer
- High print quality (200 DPI)
- Same mechanics as PlusII (100% compatible)
- Paper width: 58mm
- Paper weight: 55-70gr/mq
- Paper roll dimension Ø 50mm
- Power supply: 4-7.5Vdc (9-48 Vdc with optional board)
- 4MB internal flash memory for logos and fonts
- Interfaces: RS232/TTL (selectable with lever switch), mini USB
- Barcodes: 1D and 2D (QRCODE)
- International fonts on-board: any language available
- Sensors: head temperature, paper presence, cover open (optional)
- UL, CE, FCC approved
- The ideal solution for tough environments: from -20 up to +70 degrees
CHARACTERISTICS
- Energy-efficient functionality to reduce consumption
- RGB status LED
- FEED button
- ECO MODE
With only one model of printer you can print on "linerless" adhesive paper or standard thermal paper, allowing to meet different needs and applications
APPLICATIONS
- Workshop equipment
- Medical equipment
- PC panel and control systems
- Weighing instruments: industrial, portable
- Fire detection systems
- Sterilization equipment
- Taximeters
- Truck tachographs
- Access control
- Measurement devices: durometers, electrical devices, etc...
AVAILABLE VERSIONS
- RS232/TTL and mini USB
- Mechanical version (without electronic board)
-
-
ACCESSORIES
- Extended range module (9-48 Vdc)
What is in the box:
- Device, fixing clips
TECHNICAL SHEET
Printing Method Thermal Number of dots 8 dots/mm Columns 24, 32, 40, 42 Resolution 203 DPI Printing (mm/sec) max 50mm/sec (in absence of energy-efficient functionality) Character set European, International, Portuguese and Nordic, Chinese (GB18030), Katakana, Arabic, Greek, Turkish, Hebrew, and Cyrillic Supported Barcode 1D and 2D (QRCODE) Paper width 58 mm Paper weight from 55 to 70 g/m² Roll Dimension Ø 50mm Sensors Head temperature, paper presence, cover open (optional) Emulation Escape Command Compatibility, PlusII compatibility Interfaces RS232/TTL, mini USB Data Buffer 16Kb Flash Memory 4MB (+768 Kb internal) RAM Memory 128Kb internal + 8MB external Graphic Memory 4MB internal flash memory for logos and fonts Drivers Windows® (32/64 bit) – only on request WHQL and silent installation;
Linux (32/64 bit);
Virtual COM (Linux or Windows 32/64 bit);
Android™Software Tools PrinterSet, CustomPowerTool, Custom Windows API Power supply 4-7.5 Vdc (9-48 Vdc with optional board) Operating temperature -20 a +70 Marks UL, CE, FCC Dimensions 56.9 (L) x 85 (H) x 85 (W) mm Weight 145gr
-
