BASIC INFO
Specifications
Printing method | Thermal dot line printing method | |
---|---|---|
Total dots | 576 dots/line | |
Dot density | 8 dots/mm | |
Printing width | 72mm | |
Printing speed | Max. 60mm/sec. (480 dot-lines/sec) | |
Paper width | 80mm | |
Paper feeding pitch | 0.125mm | |
Sensors | PE sensor | Photo-interrupter |
Head temperature | Thermistor | |
Head-up | Mechanical switch | |
Operating voltage *1 | VH | DC 4.2 to 8.5V |
Vdd | DC 4.75 to 5.25V | |
Current consumption | Head (Vp=5V) | Max.: 2.5A approx. |
Motor (Vp=5V) | Max.: 0.5A approx. | |
Recommended paper | Width | 80 mm |
Thickness | 65mµ | |
Paper diameter *2 | φ83mm or less | |
Paper (Manufacturer) | TF50KS-E2D (Nippon Paper) | |
Reliability *3 | Head pulse-resistance | 100 million pulses or more |
Haed wear-resistance | 50km or more | |
Environment | Operation |
Temperature: 0 to 45°C Humidity: 35 to 85% RH (No condensation) |
Storage |
Temperature: -20 to 60°C Humidity: 10 to 90% RH (No condensation) |
|
External dimensions | 99.5 (W) × 41 (D) × 21 (H) mm | |
Weight | Approx. 95g |
-
(*1): Voltage drop at maximum current may cause the print quality problem. Please check it carefully in your environment such as control board, wiring, etc. Also please keep the voltage within the speci? ed voltage range even by the voltage drop.
-
(*2): The number of diameter varies depending on the conditions.
-
(*3): Normal temperature at 25°C, normal humidity, 12.5% printing ratio, rated energy and by use of the recommended print paper.
