BASIC INFO
LTPV445B-832-E
Easy Paper Operation Mechanism Low Voltage
Thermal Printer Mechanism
LTPV series
- Max printing speed: 85mm/sec
- Easy paper operation
- Platen latch function
- label Printing
- Support thick paper : up to 135μm*1
| Model | LTPV345 | LTPV445 | |
|---|---|---|---|
| *1 Use recommended thermal papers *2 Excluding protrusion | |||
| Printing | Method | Thermal line dot printing | |
| Number of dots/line | 576 | 832 | |
| Resolution(dots/mm) | 8 | ||
| Paper width(mm) |
80
|
112
|
|
| Printing width(mm) | 72 | 104 | |
| Speed(mm/sec max) | 85 | ||
| Paper path | Straight | ||
| Detection | Head temperature | By thermistor | |
| Platen position | By mechanical switch | ||
| Out of Paper | By photo interrupter | ||
| Power supply(V) | Operation voltage(Vdd) | 4.5 to 5.5 | |
| Operation voltage(Vp) | 4.2 to 8.5 | ||
| Peak current(A) | Head | 3.33 (8V / 64 dots) | |
| Motor | 1.0 | ||
| Service life | Pulse activation(pulse) | 100 million | |
| Abrasion resistance (km) | 50*1 | ||
| Operating temperature(°C) | 0 to 50 | ||
| Dimensions(W x D x H mm) | 93.0 X 34.5 X 39.5 *2 | 125.0 X 34.5 X 39.5 *2 | |
| Mass(g) | Approx.95 | Approx.115 | |
| Model | IFV101-01B | IFV101-01BK | |
|---|---|---|---|
| Thermal printer | LTPV345 , LTPV445 | ||
| CPU | PTV10P01 | ||
| Operating voltage(V) | Vp:4.2 to 8.5, Vcc: 4.5 to 5.5 | ||
| Character matrix(HXW dots) |
16 dots characters : 16 X 8, 16 X 16 24 dots characters : 24 X 12, 24 X 24 |
||
| Character type | Extended graphics character set | Yes | Yes |
| Katakana character set | No | Yes | |
| Optional font | Yes | Yes | |
| Downloaded character | Yes | Yes | |
| User-defined character | Yes | Yes | |
| JIS 1&2 level kanji | No | Yes | |
| Communication interface | Parallel, Serial(TTL) | ||
| Dimensions(W x D x H mm) | 70.0 X 60.0 X 10.6 | ||
| Model | PTV10P01 | |
|---|---|---|
| *1 CG ROM: Japanese, Korean | ||
