BASIC INFO
Citizen CD-S500 Receipt Printer
| Product Specifications | |
|---|---|
| Dimensions | Standard type: 156W x 247.7D x 132H mm With Auto cutter and rewinder type: 156W x 277.7D x 196.7H mm |
| Weight | Standard type: Approx.2.2 kg With Auto cutter type: 2.3 kg |
| Color Options | Black, White |
| Interface | Parallel (IEEE128), Serial (RS-232C), USB |
| Print Method | 9-pin, serial impact dot-matrix |
| Print Speed | 5 lines / sec (40 columns) maximum |
| Emulation | Citizen, Star, ESC/POS |
| Character Set | ASCII (96 characters ), International characters, Katakana, Code page 437, KATAKANA, 850, 860, 863, 865, 852, 866, 857, 858, WPC1252 |
| Graphics Printing | No |
| Data / Logo Storage | 8 K memory, 128 K bit image memory |
| Auto Cutter Lifespan | 1.5 Million cuts |
| Paper Dimensions | 57.5, 69.5 or 76.2 in wide |
| Two Color Printing Capabilities | Yes - red/black or black (two color thermal paper required for two color printing) |
| Auto Cutter | Optional |
| Wall Mountable | Yes - optional wall mount kit required |
| Mac Compatible | No |
| In The Box | Printer, AC adapter (CD-S500A models only), power cord, ribbon cassette, partition, slip prevention rubber feet, 1 paper roll, users manual |
