HSP2208-EL-MT-LL

  • Product Item:HSP2208-EL-MT-LL
  • Category: Products
  • HSP2208-EL-MT-LL
  • Product Manual:HSP2208-EL-MT-LL
BASIC INFO

HSP2208-EL-MT-LL


Printer Mechanisms

HSP2208-EL

24V Heavy duty printer with integrated cutter, easyloading version.

Highlights and features

  • Fast printing speed up to 300 mm per second

  • Powerful cutter : full and partial for paper thickness from 63 to 190 μm / 2 million cuts

  • Cuts paper up to 220 μm (10 mils) in less than 120 ms & 80 μm in less than 60 ms

  • Black mark & paper end detection for label printing

  • Very silent operation and high print quality



Specifications

Options

Applications

Highlights

Print Characteristics

Print method

Thermal

Number of dots

448

Resolution (dots/mm)

8

Max Printing speed (mm/s)

300

Print resolution (dpi)

300 (option)

200

Sensor

Paper End

Cutting Characteristics

Cutter Home Position

Mechanical Switch

Cutter Type

Full & Partial

Media Characteristics

Media Type

Ticket

Label

Paper width (mm)

60 to 62.5

Printing width (mm)

56

Min. paper thickness (µm)

63

Max. paper thickness (µm)

190

Paper loading

Easy Loading

Physical Characteristics

Dimensions (WxDxH mm)

95 x 74 x 30

Weight (g)

250

Operating Voltage

24V

Voltage range (Logic/Head)

5V or 3.3V ± 5% / 24V ± 10%

Paper detection

Opto sensor

Temperature detection

Thermistor

Head-up or Cover-open detection

Mechanical switch

Performance Characteristics

Connector Type

FPC
