FTP-628MCL103 printer head
FTP-628 MCL101/103, Easy Loading Method
Low Voltage Printers - All
Active
| Part number | Width (in/mm) | Paper path | Speed (mm/s) | Platen | Cutter |
|---|---|---|---|---|---|
| FTP-628MCL053#01 | 2-inch / 58mm | Curl | 100 | Fixed | No |
| FTP-628MCL054#01 | 2-inch / 58mm | Straight | 100 | Fixed | No |
| FTP-628MCL101#72 | 2-inch / 58mm | Curl | 100 | Detachable | No |
| FTP-628MCL103#72 | 2-inch / 58mm | Curl | 100 | Detachable | No |
| FTP-628MCL113#01 | 2-inch / 58mm | Curl | 80 | Detachable (lever/lock) | No |
| FTP-628MCL121 | 2-inch / 58mm | Curl | 100 | Detachable | No |
| FTP-628MCL353 | 2-inch / 58mm | Curl | 100 | Fixed | Yes |
| FTP-628MCL354 | 2-inch / 58mm | Straight | 100 | Fixed | Yes |
| FTP-628MCL401#01 | 2-inch / 58mm | Curl | 80 | Detachable (lever/lock) | Yes |
| FTP-628MCL451#01 | 2-inch / 58mm | Curl | 80 | Detachable | No |
| FTP-628MCL751#01 | 2-inch / 58mm | Curl | Detachable | No | |
| FTP-628MCL123 | 2-inch / 58mm | Curl | 100 | Detachable | No |
| FTP-62DMCL101#02 | 2-inch / 58mm | - | 100 | Detachable | No |
| FTP-62DMCL111#02 | 2-inch / 58mm | - | 100 | Detachable | No |
| FTP-62HMCL153 | 2-inch / 58mm | Straight | 120 | Detachable (lever/lock) | No |
| FTP-634MCL001 | 3-inch / 80mm | Straight | 50 | Fixed | No |
| FTP-634MCL002 | 3-inch / 85mm | Curl | 50 | Fixed | No |
| FTP-638MCL101 | 3-inch / 80mm | Curl | 60 | Detachable | No |
| FTP-638MCL103 | 3-inch / 80mm | Curl | 60 | Detachable | No |
| FTP-638MCL401 | 3-inch / 80mm | Curl | 60 | Detachable (lever/lock) | Yes |
| FTP-63HMCL153 | 3-inch / 80mm | Straight | 100 | Detachable (lever/lock) | No |
| FTP-644MCL001 | 4-inch / 112mm | Straight | 50 | Fixed | No |
| FTP-644MCL002 | 4-inch / 114mm | Curl | 50 | Fixed | No |
| FTP-648MCL103 | 4-inch / 112mm | Curl | 50 | Detachable (lever/lock) | No |
| FTP-648MCL104 | 4-inch / 114mm | Curl | 50 | Detachable (lever/lock) | No |
| FTP-64HMCL153 | 4-inch / 104mm | Straight | 100 | Detachable (lever/lock) | No |
To Be Discontinued
| Part number | Width (in/mm) | Paper path | Speed (mm/s) | Platen | Cutter |
|---|---|---|---|---|---|
| FTP-628MCL701 | 2-inch / 58mm | Curl | 80 | Detachable | No |
| FTP-624MCL001 | 2-inch / 58mm | - | 60 | – | No |
| FTP-624MCL002 | 2-inch / 60mm | - | 60 | – | No |
| FTP-624MCL303 | 2-inch / 58mm | - | 60 | – | Yes |
| FTP-624MCL304 | 2-inch / 60mm | - | 60 | – | Yes |
| FTP-628MCL401 | 2-inch / 58mm | - | 80 | Detachable (lever/lock) | Yes |
| FTP-633MCL400 | 3-inch / 70mm | - | 60 | – | No |
Discontinued
| Part number | Width (in/mm) | Paper path | Speed (mm/s) | Platen | Cutter |
|---|---|---|---|---|---|
| FTP-623MCL400 | 2-inch / 58mm | - | 58 | – | No |
| FTP-623MCL402 | 2-inch / 58mm | - | 58 | – | No |
| FTP-628MCL001 | 2-inch / 58mm | - | 60 | – | No |
| FTP-628MCL002 | 2-inch / 58mm | - | 60 | – | No |
| FTP-628MCL003 | 2-inch / 58mm | - | 60 | – | No |
| FTP-628MCL004 | 2-inch / 58mm | - | 60 | Fixed | No |
| FTP-628MCL053 | 2-inch / 58mm | - | 80 | Fixed | No |
| FTP-628MCL054 | 2-inch / 58mm | - | 80 | Fixed | No |
| FTP-628MCL101 | 2-inch / 58mm | - | 80 | Detachable (lever/lock) | No |
| FTP-628MCL101#11 | 2-inch / 58mm | - | 60 | – | No |
| FTP-628MCL101#21 | 2-inch / 58mm | - | 60 | Detachable (lever/lock) | No |
| FTP-628MCL101#50 | 2-inch / 58mm | - | 60 | Detachable (lever/lock) | No |
| FTP-628MCL103 | 2-inch / 58mm | - | 80 | Detachable (lever/lock) | No |
| FTP-628MCL103#70 | 2-inch / 58mm | - | 80 | Detachable (lever/lock) | No |
| FTP-628MCL113 | 2-inch / 58mm | - | 80 | Detachable (lever/lock) | No |
| FTP-628MCL201 | 2-inch / 58mm | - | 80 | Detachable (lever/lock) | No |
| FTP-628MCL201#01 | 2-inch / 58mm | Curl | 80 | Detachable (lever/lock) | No |
| FTP-628MCL203 | 2-inch / 58mm | - | 80 | Detachable (lever/lock) | No |
| FTP-628MCL203#01 | 2-inch / 58mm | Curl | 80 | Detachable (lever/lock) | No |
| FTP-628MCL383 | 2-inch / 58mm | - | 80 | – | No |
| FTP-628MCL451 | 2-inch / 58mm | - | 80 | Detachable | No |
| FTP-628MCL751 | 2-inch / 58mm | - | 80 | Detachable | No |
| FTP-62DMCL111 | 2-inch / 58mm | - | 100 | Detachable | No |
| FTP-633MCL402 | 3-inch / 70mm | - | 60 | – | No |
| FTP-62DMCL101 | 2-inch / 58mm | - | 100 | Detachable | No |
n Overview The easy loading FTP-608 MCL Series is ultra compact high speed, battery driven thermal printer, printing on 2-inch wide paper (58mm) where platens are removable. Our original platen removal mechanism improved paper loading and maintenance. The FTP-608 MCL series can be used for a variety of applications, such as portable terminals, POS, ticket issuing terminals, label printers, banking terminals, and measurement and medical equipment. n HIGHLIGHTS • Easy loading type Our original platen removal mechanism improved paper loading and maintenance. • Ultra compact Height 15.5 mm, width 70.3 mm, depth 33.0 mm for the 2 inch model. • High speed printing It can print at 80 mm/s (640 dotlines/s) maximum by using Fujitsu's unique head drive control. • High resolution printing 8 dots/mm of resolution p
