MTP401-40B-E

  • 产品项目:MTP401-40B-E
  • 产品分类: 产品展示
  • MTP401-40B-E
  • MTP401-40B-E
  • 产品手册:MTP401-40B-E
基础信息

MTP401-40B-E

Model MTP102-16B MTP201-20B MTP201-24B MTP401-40B MTP201-G166
*1 Use recommended thermal papers. *2 Excluding protrusion.
Printing Type Character Graphic
Method Thermal serial dot printing
Paper width (mm) 38+0-1 58+0-1 80+0-1 58+0-1
Printing width (mm) 26.4 45.9 46 66.7 46
Speed (line/sec) max 1.2 1.0 0.9 0.5 0.9
Paper path Curved
Character matrix (H×W dots) 7 × 5
Character size (H×W mm) 2.4 × 1.2 2.4 × 1.6 2.4 × 1.4 2.4 × 1.2 2.4 × 1.4
Number of columns 16 20 24 40 24
Direction Left to right
Timing Synchronized with the tachogenerator
Line spacing (mm) 3.8 2.8
Character spacing (dot) 2 0
Detection Mechanical switch
Power supply (V) 4.0 to 6.0
Peak current (A) 3.2 (5V on)
Service life (Lines) 500,000*1
Operating temperature (˚C) 0 to 50
Dimensions (W×D×H mm) 48.0 × 31.0 × 13.8*2 70.0 × 34.0 × 14.4*2 91.5 × 35.5 × 20.0*2 70.0 × 34.0 × 14.4*2
Mass (g) Approx. 35 Approx. 40 Approx. 50 Approx. 40
